Higo signal waterproof connectors for e-bike system

  • $80.00
Tax included. Shipping calculated at checkout.


5 pin Higo signal waterproof connectors.this connectors is designed with waterproof&screw- locking capacity,with 2-pin main power wires to 5pin signal wires,for e-bike system.

After placed an order successed please contact us and tell us what length and specification you need Via:Motowoks@hotmail.com.

Keywords:

ebike battery connector

ebike battery connector types

ebike power connector

ebike charger connector

battery charger terminals

ebike battery connections

For more connectors please refer to:https://www.mutuallc.com

Specifications:

Temperature Range:-25℃~+80℃

Rated Voltage: 36 V/48 V/60 V/72 V DC /60 V AC

Rated Current:25 A signal: 5A

Contact Resistance:≤10 mΩ

Insulation Resistance:≥20 MΩ

Terminal Material: Copper Alloy(Gold Plated)

Protection Level: IP 65-667

Contact Durability: 3000 times

Wire Specification:0.34 mm²+ 4.0 mm²/2.0 mm²





Custom cable length.For more design please contact us email:Motowoks@hotmail.com

Tips you want to know:

About shipping,we will process your order when payment is done,delivery option would be standard Fedex/TNT/UPS according to your country address,the door to door shipping time is about 7-9 days.The default address would be the bill address,please leave a correct address and telephone number when check out.

About warranty,our products do 1 year warranty for customers,if there are issue parts due to our products quality cause we will resend spare parts for free.
