2 wire waterproof connector battery charger connector

  • $50.00
Tax included. Shipping calculated at checkout.


The 2 wire waterproof connector/2 prong waterproof connector is used for battery charger connector and as ebike battery connector it has IP66 waterproof capacity,the 2 pin connector can be used for ebike battery connector or called ebike power connector,also for outdoor cable connector as its good performance on waterproof.
This battery connector with 2 pin main power wire,this connector is used for charging battery like bafang battery connector(Bafang BBS mid motors).The battery connector with gold surface on the pins makes sure the efficient current transportation.This connector plug-in&out can be 200 times which is compatible with battery long using life.The charging connector connector is an ideal choice for 15A battery charging.

After placed an order successed please contact us and tell us what length and specification you need Via:Motowoks@hotmail.com.

Keywords:

ebike battery connector

ebike battery connector types

ebike power connector

ebike charger connector

battery charger terminals

ebike battery connections

bafang battery connector

For more connectors please refer to:
https://www.mutuallc.com

battery connector

Specifications:

Temperature Range:-25℃~+80℃

Rated Voltage: 48 V AC/DC

Rated Current:15 A

Contact Resistance:≤10 mΩ

Insulation Resistance:≥20 MΩ

Contact Material: Copper Alloy Plated with gold which conforms to military standard

Protection Level: IP 65-667

Contact Durability: 3000 times



Withstanding Voltage:700V



Mating type: Insertion Force:80N Max,Extraction 30N Min80N Max,Extraction 30N Min



Mating Cycles:200 times



External diameter:14.5mm



Mating length:67mm



Wire section:1.5 m㎡



Protection Degree:IP66





Custom cable length.For more design please contact us email:Motowoks@hotmail.com

Tips you want to know:

About shipping,we will process your order when payment is done,delivery option would be standard Fedex/TNT/UPS according to your country address,the door to door shipping time is about 7-9 days.The default address would be the bill address,please leave a correct address and telephone number when check out.

About warranty,our products do 1 year warranty for customers,if there are issue parts due to our products quality cause we will resend spare parts for free.
